NOR 4082 High-Level and Overfill Alarm System – Reliable Protection for Marine Cargo Operations
Prevent spills, protect safety, and ensure compliance – automatically.
When handling liquid cargo, there is no room for error. The Vimex High-Level and Overfill Alarm System (HLOAS) provides precise and proven level control that prevents overfilling, protects crew and cargo, and ensures full compliance with IMO and class regulations.
Built for tankers carrying LPG, LNG, and chemical cargoes, the NOR 4082 system combines robust mechanical design with advanced monitoring and flexible alarm configuration — giving you dependable protection with minimal maintenance.
Want to know more about our solutions from Vimex?
NOR 4082 Series – Designed for Every Tank Type
All models use a titanium float (optional acid-proof steel) that moves with the liquid level to activate a reed switch, each circuit protected by an intrinsically safe relay / zener barrier.
System Overview
The Vimex HLOAS is based on a PLC-controlled architecture that monitors each tank individually.
Each alarm level is shown clearly on the operator panel, giving immediate visual and audible indication of 95%, 98.5%, and 99% levels.
Signals are generated by magnetic float-operated switches (NOR 4082 series) mounted at the tank top.
Communication options:
- Hardwired or via RS-485/TCP fieldbus
- MODBUS RTU, BIT BUS or TIWAY network integration
Power supply:
110/230 VAC, 50/60 Hz @ 10 A, 600 VA (max)
Why Choose the NOR 4082i
The NOR 4082i represents the next generation of Vimex alarm systems – offering digital communication, simplified maintenance, and compatibility with existing tank installations. Its modular sensor design allows tip replacement from the tank top without gas-freeing, reducing downtime dramatically. The non-length-specific configuration means fewer spare parts and faster servicing.
Key benefits:
- Easy retrofit installation – no tank entry required
- Field-replaceable sensor tips for any level configuration
- RS-485 digital interface for modern monitoring systems
- Certified for DNV, LR, BV, NK, and CCS approval
- Designed for LPG/LNG and chemical cargoes
Built to Last
- Cabinet materials: cold-rolled, corrosion-protected steel with epoxy varnish (RAL 7035 Grey)
- Environmental tolerance: –25 °C to +70 °C, 100 % humidity, 0.7 g vibration
- Designed and tested to CENELEC EN 50081-2 / 50082-2
- Type approval: DNV-certified for marine installations
Applications
- LPG / LNG tankers and carriers
- Chemical and product tankers
- FPSOs and storage terminals
- Ballast and slop tanks
- Any installation requiring multi-level alarm protection
